Introduction

The MS 600X secure platform family

The family features two powerful tamper resistant CC EAL5+ certified secure microcontroller platforms, each built on 50MHz 32 bit ARM SC300 core. With a choice of USB, SPI or I2C they offer high flexibility and fast time-to-market with its 1MB Flash & 24K RAM, and are ideal to power secure data storage devices, FIDO USB-tokens or Crypto Wallets.
SEAL SQ semiconductors secure arm platform MS 600X-2 (2)-1
MS 6003

Many secure USB tokens are built by adding a USB bridge to a PKI Smart Card chip because of the lack of an integrated solution. MS 6003 offers that unique USB interface integration.

Key Technical Features
  • 50MHz 32-bit SC300 ARM SecureCore
  • 1MByte Flash, 24kB RAM
  • TDES, AES, RNG, PKI co-processors and libraries
  • 8 Endpoints USB 2.0 Full Speed Interface with Clock Recovery
  • ISO 7816, I2C, SPI, 8 GPIOs
  • Nano Power RTC (<300nA)
  • 8kV contact IEC 61000-4-2 ESD protection
  • 2.7V to 5.5V
  • -40°C to 105°C Operating Ranges
  • Available in Wafers & 4x4mm QFN20 package
  • Optional provisioning & personalization in CC EAL5+ secure environment
Key Benefits
Fully integrated USB interface:
  • Optimized BoM for USB Authentication Tokens: No need to use a dual chip solution , No external crystal required, No discrete ESD protection required, No RTC
  • Highest standard of hardware security certification CC EAL5+
  • Industry Standard, High Performance 32-bit CPU (ARM SC300)
  • Large Flash for flexibility: Time to Market, logistics, field upgrades
  • Flexible choice of USB, I2C or SPI
  • Optional provisioning & personalization in CC EAL5+ secure environment
Download

MS6003 Block Diagram
SEALSQ MS6003 Core Architecture

Applications

  • USB Tokens
  • Second Factor of Authentication
  • One Time Password Generators
  • FIDO Tokens
  • Software Monetization
  • Secure Login
  • Crypto Wallets
  • Secure Hard Drives
SEAL SQ semiconductors secure arm platform MS 600X-2 (2)-1
MS 6001

The MS 6001 is a cost effective version of the platform without the integrated USB interface for applications that do not require it.

Key Technical Features
  • 50MHz 32-bit SC300 ARM SecureCore
  • 1MByte Flash, 24kB RAM
  • TDES, AES, RNG, PKI co-processors and libraries
  • ISO 7816, I2C, SPI, 5 GPIOs
  • 2.7V to 5.5V
  • 40°C to 105°C Operating Range
  • Available in Wafers & 4x4mm QFN20 package
  • Optional provisioning & personalization in CC EAL5+ secure environment
Key Benefits
  • Cost effective
  • Highest standard of hardware security certification CC EAL5+
  • Industry Standard, High Performance 32-bit CPU (ARM SC300)
  • Large Flash for flexibility: Time to Market, logistics, field upgrades
  • Flexible choice of I2C or SPI  embedded system interfaces
  • Optional provisioning & personalization in CC EAL5+ secure environment
Download

MS 6001 - Block Diagram
SEALSQ MS6001 Core Architecture

Applications

  • Embedded Systems
  • Physical/Logical access control systems

They trust us

IStorage-Logo
Siemens_Logo
Legic-Logo
Neowave-logo

Certifications

The MS 600X Hardware platform offers the highest hardware security credentials and is managed by an organization compliant with ISO 27001 quality and safety standards.

Logo-certificationCCC-eal-5+
ISO 27001
White Paper SEAL SQ White Paper NEOWAVE FIDO FINAL WKEY

A highly secure FIDO2 token powered by MS 6003

Learn about FIDO authentication and how Neowave leveraged the MS 6003 to build “Winkeo”, a FIDO2/FIDO U2F token that has recently been awarded with high security labels (ANSSI, Cybersecurity made in Europe…)
